Automatic Lightweight EPS Cement Sandwich Wall Panel Machine, Construction Partition Wall Panel Making Machine

Basic Info.

Model NO.	wall panel machine
Thickness of The Light Weight Wall Panel	50mm, 60mm, 75mm, 90mm, 100mm, 125mm, 150mm
Grade	7
Light Weight EPS Wall Panel	550kg ---650kg
Power	380V or 220V
Transport Package	Export Standard
Specification	2440X610mm
Trademark	Hongfa
Origin	Guangxi, China (Mainland)
HS Code	8474802000
Production Capacity	50,000-1,000,000m2/Year, 50,000-1,000,000m2/Year

Product Description

Automatic Lightweight EPS Cement Sandwich Wall Panel Machine, Construction Partition Wall Panel Making Machine
Wall panel for concrete precast houses: 1.Full Automatic 2.Eco Saving and Advanced Technology 3.Low cost 4.ISO9001-2000 Take an EPS Wall Panel production line with annual capacity 200,000m2 for example (700 m2 / day): (1). An EPS Wall panel production line with annual capacity 200,000m2. (2).The raw materials cost to produce one square meter of EPS Wall panel ( take 90mm thickness panel for example).

Materials	Cement	Fly ash	EPS	additive	Silica panel	Water and power	Labor costs	total
RMB/m2	8	3.4	6	0.5	13.4	0.52	3	34.82

(3).Costs above calculated based on the below cost table:

Materials	Cement(ton)	Fly ash(ton)	EPS(ton)	Additive(ton)	Silica panel(m2)	Water	Power(kw)	Worker salary(person/month)
Price(RMB)	330	140	13000	5000	6.7	0.5	0.9	3000

(4).Other costs

Cost categories	Management costs	Equipment depreciation	Depreciation of buildings	Maintenance Charge	total
RMB/m2	1.00	0.50	0.30	0.20	2.00

(5).Based on the above table, the total production cost is: 37 RMB/m2.(6).Annual Estimate Benefits According to China domestic normal selling price:EXW 65RMB/m2

Annual Output Value(RMB)	Selling expense(RMB)	Annual production cost(RMB)	Annual Profits (RMB)
65×200,000m2	13,000,000×5%	200,000x 37	13,000,000-650,000-7,400,000
13,000,000	650,000	7,400,000	4,950,000

Main Feasture: (1)The machine adopts PLC and touch screen control, automatic filling, electronic weighing, temperature control, material level control to realize automatic production. (2) With the same machine, it can adjust the panel size and thickness. The thickness will be from 60 to 180mm. (3) The closed constant pressure foamng barrel features of high heating efficiency and saves stem. (4)High precise guiding pressure reducing valve controls the temperature and steam pressure of the closed barrel, ensuring the outcome pressure of the valve constant and the inner temperature controlled wihin ±1%, which keeps the foamed material equal and prevents the bead agglomerate because of the bad temperature control. (5)With photoelectric or vibration sensor to control material level, ensuring density tolerance within ±3%. (6)The machine is equipped with fluidized bed dryer, including drying, automatic sieving, depluming and material conveying to silos. (7)Most components are of world-famous brands, with reliable performance, stable quality, long service life and low maintenance cost. (8)The machine can realize the primary and second expansion.How are the land,water,power required to set up an EPS light weight wall panel production line?Water requirements: to produce 60m2 panel(9 cm thickness as example) required one ton of water. No special requirements for water quality, clean water can be used for production.Electricity requirement: installed power 30 kw (depending on the capacity).Requirements on air and steam: Air compressor and boiler.Land requirements: 1200-2000m2 workshop and 9 meters high (depending on the capacity). Suggested Staffing Table:

Position	Amount(Person)
Moulding/poring	1
Demoulding&Packing	1
EPS Expander Operation/raw materials	1
Mixer Operation	1
Transportation	1
Total	5
